IKA RH Basic Magnetic Stirrer With Heating With Swiss Plug
Sold by: Analisa Resources
Available Soon
Part #: 4.721 116Manufacturer #: 0025006150
Estimated shipping time:Contact us via live chat or via contact us page
Product overview
The IKA RH basic Magnetic stirrer with heating with Swiss plug is a magnetic stirrer for heating and mixing samples in chemistry and life-science laboratories. A laboratory hotplate-stirrer designed for reliable, repeatable heating and stirring, suitable for unattended operation.
Key Features:
- Brand: IKA
- Product Type: Magnetic stirrer
- Material: Aluminium heating plate
- Plug type: Swiss (CH) plug
- Temperature control: Integrated control with PT 1000 temperature sensor
- Probe connection: DIN 12878 socket for a contact thermometer (e.g. ETS-D5)
- Safety: Adjustable safety temperature limit and hot-surface warning indicator
- Additional features: Optimised PID control for stable temperature control without overshoot; Adjustable heating rate in percent for sensitive samples; User-friendly touchscreen for intuitive operation; USB-C interface
- Application: Heating and mixing samples in chemistry and life-science laboratories
- Scope of supply: Magnetic stirrer, contact thermometer ETS-D5, support rod H 16 V, cross sleeve H 44, holding rod H 38, IKAFLON® 30 magnetic stirring bar, screwdriver
Backed by IKA, this magnetic stirrer is a dependable choice for heating and mixing samples in chemistry and life-science laboratories where consistency matters.
Product Specifications
- Control accuracy heating temperature±0,2 K
- Depth217 mm
- Dimensions (WxDxH)168 x 217 x 100 mm
- DisplayScale
- Power supply frequency50/60 Hz
- Heating capacity600 W
- Heating temperatureRT ... 310 °C
- Height100 mm
- IP codeIP 22
- Material stirring surfaceAluminium alloy
- Max. heating rate5.5 K/min
- Max. heating temperature310 °C
- Max. permitted ambient temp.40 °C
- Max. relative humidity rate80 %
- Max. safety temperature360 °C
- Max. speed1500 1/min
- Max. stirring capacity15 l
- Max. voltage230 V
- Min. permitted ambient temperature5 °C
- Min. safety temperature50 °C
- Min. speed100 1/min
- Min. voltage220 V
- No. of stirring positions1
- Permitted ambient temperature5 ... 40 °C
- Plug typeCH
- Power supply220 ... 230 V, 50/60 Hz
- Rated capacity620 W
- Safety temperature50 ... 360 °C
- Speed100 ... 1,500 1/min
- TypeRH basic
- Type of auxiliary energyMains connection
- UNSPSC41103806
- Weight2.1 kg
- Width168 mm
- With connection ext. temperature sensorYes
- With timerNo
- Working area Ø135 mm
