Representative Image

IDCP Dino-Lite Edge Digital Microscope USB Special Lighting Fluorescence Excitation 525nm Emission 570nm

Brand:IDCP

Magnification

Type

Specifications

Compare models
Description
Fluorophore: Cy3, TRITC, excitation 525 nm, emission 570 nm
Light type
LED
Magnification
20x ... 220x
Resolution
1.3 MP
Type
AM4115T-YFGW
UNSPSC
41111766

RM 5,172.75

Inc. GST

Available soon

Product description

The IDCP Dino-Lite Edge Digital Microscope features specialized fluorescence lighting with excitation at 525nm and emission at 570nm, delivering high-contrast imaging for fluorescent samples. Designed for advanced fluorescence imaging in life sciences, pathology, and material analysis, this compact microscope includes switchable white LED lighting for easy sample localization and focus. Its USB 2.0 interface ensures user-friendly connectivity and real-time viewing.

Key Features:

  • Brand: IDCP
  • Resolution: 1.3 megapixels (1280x1024) for clear image capture
  • Lighting: Fluorescent LEDs with 525nm excitation and 570nm emission; switchable to white LED
  • Filter: Long-pass emission filter for enhanced fluorescence visibility
  • Connectivity: USB 2.0, 30 fps for smooth, real-time imaging
  • Application: Ideal for fluorescence imaging in biological, medical, and material research

Scope of Supply:

  • Carrying pouch
  • Software CD for Windows and Mac OS
  • Calibration slide
  • Manual

This compact and user-friendly Dino-Lite fluorescence microscope offers excellent imaging performance for researchers and professionals requiring portable fluorescence solutions.

Downloads

Accessories

Accessories for USB Hand held microscopes

ProductDescriptionUNSPSCMfr#Part#AvailabilityPrice
Table top stand with quick-release incl. extension arm41111700RK-10A6.285 944RM 2,216.50
Metal stand, vertical and horizontal positioning41111700RK-06A6.275 263RM 1,595.00
Three-point joint articulating mount, with clamp41111700MS53B6.320 213RM 2,431.00
Jointed elbow-arm type stand, with base41111700MS53BA26.320 214RM 2,937.00

Compare similar models

Dino-Lite edge digital microscope USB special lighting-Fluorescence, excitation 525nm, emission 570nm

Manufacturer P/N

AM4115T-YFGW

Part Number

6.285 937

Manufacturer

IDCP

Description

Fluorophore: Cy3, TRITC, excitation 525 nm, emission 570 nm

Dino-Lite edge digital microscope USB special lighting-Fluorescence, excitation 480nm, emission 510nm

Manufacturer P/N

AM4115T-GFBW

Part Number

6.285 936

Manufacturer

IDCP

Description

Fluorophore: GFP, FITC, excitation 480 nm, emission 510 nm

Dino-Lite edge digital microscope USB special lighting-Fluorescence, excitation 400nm, emission 430nm

Manufacturer P/N

AM4115T-CFVW

Part Number

6.285 935

Manufacturer

IDCP

Description

Fluorophore: DAPI, excitation 400 nm, emission 430 nm

Dino-Lite edge digital microscope USB special lighting-Fluorescence, excitation 575nm, emission 610nm

Manufacturer P/N

AM4115T-RFYW

Part Number

6.285 938

Manufacturer

IDCP

Description

Fluorophore: TxRED, mCherry, excitation 575 nm, emission 610 nm

Dino-Lite edge digital microscope USB special lighting-Fluorescence, excitation 620nm, emission 650nm

Manufacturer P/N

AM4115T-DFRW

Part Number

6.285 939

Manufacturer

IDCP

Description

Fluorophore: Cy5, excitation 620 nm, emission 650 nm

Dino-Lite Edge Digital Microscope USB 1.3MP, 400~470x, excitation 480nm, emission 510nm, AMR

Manufacturer P/N

AM4515T4-GFBW

Part Number

4.712 512

Manufacturer

IDCP

Description

Fluorophore: GFP, FITC, excitation 480 nm, emission 510 nm

Dino-Lite Edge digital microscope USB 1.3MP, 20~220x,ex: 480nm em: 510nm, ex: 575nm em: 610nm

Manufacturer P/N

AM4115T-GRFBY

Part Number

6.490 294

Manufacturer

IDCP

Description

Fluorophore: GFP/FITC & TxRed/mCherry, excitation 480/575 nm, emission 510/610 nm
