DWK Duran GLS80 Stirred Reactor Cap, with Anchor-Shaped Stirrer Spindle

Specifications

HS Code #
39269097
Description
Stirred reactor cap, anchor type, incl. shaft
For
GLS 80®
UNSPSC
41121800

Alternative in-stock items

RM 2,156.00

Inc. GST

Available soon

Product description

The DWK Duran GLS 80 Stirred Reactor Cap with Anchor-Shaped Stirrer and Spindle is designed for seamless integration with GLS 80 stirred reactor systems. Crafted from high-quality materials including polypropylene (PP), PTFE, PEEK, and stainless steel, this cap features a robust anchor-type stirrer for enhanced mixing performance when driven by a standard magnetic stirrer (up to 500 rpm).

Key Features:

  • Brand: DWK Duran
  • System Compatibility: GLS 80 stirred reactor systems (500, 1,000, or 2,000 mL bottles)
  • Stirrer Type: Anchor-shaped magnetic stirrer with spindle
  • Materials: Cap – PP; Shaft – PTFE/PEEK; Contact surfaces – stainless steel
  • Operating Speed: Up to 500 rpm (not recommended above 400 rpm for liquids >10 mPa·s)
  • Ports: Multiple threaded ports (2 × GL 14 and 2 × GL 18) for media and gas handling
  • Autoclavable: Yes
  • Anchor Stirrer Diameter: 62 mm; Shaft diameter: 6 mm; Height: 62 mm
  • Sterility & Flexibility: Compatible with sterile transfer systems (tubing 1.6–12 mm OD)

This DWK Duran accessory offers flexible, sterile-compatible mixing in closed reactor systems, enhancing efficiency and performance in fermentation, dissolution, and other mixing applications.

Downloads

Compare similar models

GLS80 stirred reactor cap with anchor shaped stirrer, spindle

Manufacturer P/N

1200379

Part Number

9.197 379

Manufacturer

DWK Life Sciences​

Description

Stirred reactor cap, anchor type, incl. shaft

Magnetic stirrer, blade shaped for GLS 80 reactor stirrer

Manufacturer P/N

1200382

Part Number

9.197 382

Manufacturer

DWK Life Sciences​

Description

Stirrer, impeller type

Spare spindle for GLS 80 stirred reactor, stainless steel, incl. PEEK screwing

Manufacturer P/N

1200386

Part Number

9.197 386

Manufacturer

DWK Life Sciences​

Description

Spare shaft, stainless steel, incl. PEEK connection

Magnetic stirrer, anchor shaped for GLS 80 reactor stirrer

Manufacturer P/N

1200383

Part Number

9.197 383

Manufacturer

DWK Life Sciences​

Description

Stirrer, anchor type

Spare screw cap set for GLS 80 stirred reactor (blue/grey)

Manufacturer P/N

1200385

Part Number

9.197 385

Manufacturer

DWK Life Sciences​

Description

Spare screw cap, PP blue/grey

Frequently asked questions

It is designed for seamless integration with GLS 80 stirred reactor systems. Crafted from high-quality materials including polypropylene (PP), PTFE, PEEK, and stainless steel, this cap features a robust anchor-type stirrer for enhanced mixing performance when driven by a standard magnetic stirrer (up to 500 rpm).
